Echo SRM-420TES/U X-Series Petrol Brush Cutter

Description

Built for professionals, designed for large-scale commercial application and driven by a Japanese 41.5cc engine, the Echo SRM-420TES/U high torque brush cutter weighs just 8.7kg, has semi-automatic decompression for easy starting and features a cowhorn handlebar.

The Echo Easy Start system is a culmination of years of unique and innovative developments. It works to minimise the effort required to start the engine with greatly reduced pulling power and vastly reduced kick back effect. In most cases the effort required to pull the starter is reduced by up to 50 per cent compared to standard models.

The brush cutter generates outstanding levels of torque, which means one thing - greater cutting power! With a 1:2.07 gear reduction ratio, the cutting head spins at one-and-a-quarter times per engine cycle. The increase in cutting torque enables the use of a 51cm cutting swathe, which increases work rate by 17 per cent. The 'Tap and Go' twin nylon line head is bigger than the conventional head, maximising line storage.

The Echo SRM-420TES/U features an anti-vibration system which includes plastic casing and rubber cushions inside. These are soft enough to reduce vibration without effecting manoeuvrability.

A professional, heavy-duty, two-stage air filter provides geater durability and filtration than a standard filter. The cooling air intake is at the rear of the machine, which reduces the amount of debris being sucked in and, as a result, the time required for daily maintenance. In addition, the process works more effectively to cool the engine.

Every aspect has been engineered from the ground up for the professional, to ensure you can finish one job and move on to the next.

Echo power tools come with a two year warranty in professional use, and five years for domestic use (subject to product registration and servicing).

X-Series means Echo's best-in-class products. More power, lighter weight and performance that will noticeably increase your productivity. Designed for professionals who demand the best and highest quality tools. X-Series engines make this line-up exceptional. They offer a revolutionary combination to get jobs done faster with less fatigue.

Specification

More Information
Brand	Echo
Engine Type	2-stroke
Displacement	41.5cc
Rated Power Output	1.78kW / 2.24ps
Start Method	Recoil
Ignition System	CDI
Start Assist System	ES-start
Carburettor	Diaphragm, horizontal-draft with purge bulb
Spark Plug	BPMR8Y
Fuel Tank Capacity	0.69L
Fuel / Oil Mixture	50 : 1
Fuel Consumption	1.05l/h
Gear Reduction Ratio	1.33
Cutting Head	B6 M10L / EA-X047-001121 B6
Brush Cutter Blade	Blade capable, not included (arbour diameter for blade: 25.4mm)
Nylon Line Head	Dual nylon line cutting head
Line Diameter	Up to 3.3mm
Rotating Direction	Counterclockwise as viewed from top
Shaft Type	Straight, solid with serration (10-tooth)
Shaft Diameter	28mm
Drive Shaft Diameter	8mm
Handle Type	Cowhorn
Harness	Included
Vibration	Left handle: 4.3m/s / Right handle: 2.7m/s
Sound and Noise Data	Sound pressure level: 96.6dB(A) / Sound power level: 110.3dB(A)
CO²	952g/kW.h
Assembled Dimensions	L: 185.2cm x W: 70cm x H: 62cm
Dry Weight	8.7kg
Warranty	5 year consumer, 3 year professional
Promotional Image	/e/c/echo-x-series_9.jpg

Features

Ergo pro harness Connect your tool to the Ergo pro harness with one simple click. Long, arduous jobs are now a breeze as the tool's weight is supported and you have a consistent range of motion. An emergency tool release lever gives you the option to instantly disconnect your tool should the need arise.
	Super anti-vibration system Featuring a four-point super anti-vibration engine mount for operator comfort. Less vibration means less fatigue and increased accuracy.
High torque gear case The high torque gear case regulates rpm to ensure clean cutting whilst moving through varying intensities of brush. This means that, whether you're cutting short grass or tall, dense brush, you will always have optimal power to pass through cleanly.
	Other key features:- Powerful two-stroke 41.5cc Echo engine Stage 2 low emissions compliant for reduced exhaust emissions Easy Start system for quick, effortless starting High torque head for increased cutting power from a smaller engine 'U' handle design 'Tap and Go' system releases more line with a single tap Tough magnesium crankcase Air intake at rear of machine provides effective engine cooling method and reduces daily maintenance as less debris is sucked in Heavy duty, two-stage air filter provides both durability and easy maintenance Lower weight enhances user comfort without compromising performance
Echo X-Series X-Series means Echo’s best in class products. More power, lighter weight and performance that will noticeably increase your productivity. Designed for professionals who demand the best and highest quality tools. Best-in-class features Each model has specific, best-in-class features that are designed to help green space professionals perform their jobs better in their respective applications. Being light weight and more powerful with features like vibration reduction and longer run times all contribute to getting one job done faster and moving onto the next. Withstand tough conditions Echo X-Series equipment is so extreme, that only the hardest working and committed can challenge the limits of its capabilities. The equipment is tested in extreme conditions to assure easy starting and smooth operation, whatever the environment.
