solo by AL-KO Comfort MH 770 Petrol Cultivator

Description

If you are looking for a device for cultivating, aerating or loosening the soil, then solo by AL-KO offers the perfect solution in the form of the MH 770 Comfort petrol cultivator.

The German-engineered MH 770 Comfort is compact, lightweight and manoeuvrable, yet very efficient when it comes to preparing the soil before sowing, decompacting it and working in nutrients, fertiliser and fresh topsoil.

A working width of 77cm and six sets of blades perfectly cope with regularly cultivated ground up to a working depth of 33cm. A cover made of strong steel sheet protects the operator against stones or soil thrown out.

Powered by a 196cc 3.45kW engine, the solo by AL-KO MH 770 has powerful traction even on heavy soils. The machine stays on track with the adjustable guide spur, which also acts as a drag stake to serve as a brake to slow the cultivator's forward motion to ensure you always dig at the correct depth for the area. With two forward gears, you can easily adjust the working speed and productivity to your requirements, whilst the reverse gear makes manoeuvering easier and enables effortless operation.

The long ergonomic handle, which can be variably adjusted sideways and in height without the use of tools, ensures particular ease of use and operator comfort. When the handlebar is moved to an offset position, an area can be worked without having to step on previously worked and therefore loosened soil. Protective crop discs limit the working width to ensure protection of existing plantings.

Further protection is offered by the integrated front bumper which protects the engine during use. The transport wheel can be adjusted easily and without tools from working to transport position. The folding handle and removable front wheel greatly facility transport of this machine.

Several accessories can be attached to this tiller such as a ridger or bed plough. For better traction, it is advisable to attach the optional steel wheel set when using ploughs.

Specification

More Information
Brand	solo by AL-KO
Engine	AL-KO
Engine Type	4-stroke
Displacement	196cc
Power	3.45kW
Rated Speed	3100rpm
Start Method	Recoil
Gears	2 forward + 1 reverse
Working Area	Up to 670m²
Tilling Width	77cm / 30"
Tilling Depth	33cm
Tines	6 sets discs / 4 tines per unit = 24
Tilling Speed	1st gear: 71 min-1 2nd gear: 97 min-1 Reverse: 53 min-1
Crop Protection Discs	Yes
Handle Type	Adjustable sideways and in height
Transport Wheels	1
Sound and Noise Data	Left ear: LpA = 79.4dB(A) Right ear: LpA = 79.6dB(A) / K = 1.5dB(A)
Vibration Level Data	Left handle: 0.372m/s² Right handle: 0.584m/s² K = 1.5m/s²
Assembled Dimensions	78cm x 44cm x 65cm
Weight	67.0kg
Global Trade Item Number	4003718063226
Warranty	Standard domestic: 2 years Extended domestic: 5 years (subject to online registration and annual service) Commercial: 90 days
Promotional Image	no_selection

Features

Use

Ideal for digging new ground or turning soil.

AL-KO Power

AL-KO engines offer power, performance and exceptional reliability.

Offset Handle

The handles an be set to an offset position, allowing work alongside fences and walls.

Height Adjustable

The handles can be fully adjusted to suit the height of the operator ensuring comfort and control.

Control

Ergonomically designed control levers make cultivator operation simple.

Drive

Featuring two forward speeds and one reverse to cover large areas quickly.

Drag Stake

The adjustable drag stake ensures you always dig at the correct depth for the area.

Crop Discs

Crop protection discs included.

Blades

Specially designed blades offer great digging performance.

Wheels

Transport wheels are easily removed during operation.

Front bumper

Integrated front bumper protects the engine during use.

Brand

ABOUT AL-KO GARDEN + HOBBY.....

AL-KO Gardentech acquired Sindelfingen-based SOLO Kleinmotoren GmbH to strengthen its range of garden machinery. The AL-KO range has been expanded with ride-on mower and lawn tractors, petrol chainsaws and trimmers, providing customers with expertise and strong, tradition-rich brands in one product range.

Founded in 1931 by Alois Kober as a small metalworking shop in southern Germany, AL-KO has become a global player comprising of more than 50 sites in 30 countries. The AL-KO Group today employs over 4,200 people worldwide covering three business divisions - Vehicle Technology, Garden + Hobby, and Air Technology. All AL-KO employees take great pride in the quality products they manufacture.

For greater enjoyment in the garden

For more than 50 years, AL-KO has been developing and designing innovative garden tools for an extremely wide range of requirements and applications. Not only do AL-KO tools reflect its many years of expertise in technology and function, they also set new standards in terms of design.

When the best is expected

With Germany efficiency, AL-KO's research and development engineers create pioneering garden tools from hundreds of individual parts. Materials of the highest quality, ingenious technology, perfect ergonomics and a sure feel for form and deteail make AL-KO's garden tools unmistakable.

The rigourous quality requirement that characterises the AL-KO band is guaranteed through its comprehensive technology programme that is consistently planned and implemented by AL-KO development engineers, designers and technicias - from the first design, to prototype construction and the end product.

Why not take the plunge into the world of AL-KO and get to know its high-quality products - without doubt you will find just the right implement for your requirements. AL-KO has everything you need for the garden, whether you are mowing, trimming, shredding, mulching, scarifying, lawn raking, cultivating, splitting or clearing ...

Warranty

All machines come with a two year warranty, following this machines have an extended warranty depending on the range and annual servicing by an authorised AL-KO dealer.

Award-winning

The German Design Award is the premium prize of the “Rat für Design”. With its global spectrum and international appeal, it is one of the most respected awards in the design landscape across all industries. Since 2012, the German Design Award has been identifying key design trends, presenting them to a broad public and honoring them. Every year, extraordinary submissions in product design, communication design and architecture are chosen, which cover all areas of daily life.

The “Winner” of the German Design Award, which AL-KO received for its solo® by AL-KO Premium pro lawn tractor and its solo® by AL-KO Robolinho® robotic lawn mower in the Gardening and Outdoor Living category, recognises outstanding work and exemplary implemented design services.
